1650mm Stainless Steel Tracking Shear Cut to Length Line with Double Leveler
XIONGJIN MACHINERY supplied this 1650mm stainless steel tracking shear cut to length line for high-efficiency coil-to-sheet processing.
The production line is designed for processing stainless steel coils from 0.2–3.0 mm thickness, with a maximum processing width of 1650 mm.
A key feature of this production line is the double leveler system, which provides improved strip flatness and more stable finished sheet quality before cutting.
Main Specifications
- Maximum Processing Width: 1650 mm
- Thickness Range: 0.2–3.0 mm
- Material: Stainless Steel Coil
- Cutting System: Tracking Shear / Flying Shear
- Leveling System: Double Leveler
- Application: Stainless Steel Coil to Sheet Processing
- Servo Length Measuring and Feeding
- Continuous Coil Feeding
- Sheet Conveying System
- Customized Stacking System
- PLC + HMI Control
Tracking Shear / Flying Shear System
The tracking shear system follows the moving strip during the cutting cycle, allowing the coil to continue feeding while the sheet is being cut.
Compared with a conventional stop shear cut to length line, this configuration helps improve production efficiency and is suitable for customers requiring continuous and higher-speed coil processing.
Double Leveler System
The double leveler configuration is one of the key features of this 1650mm cut to length line.
Two leveling sections help improve strip flatness and provide more stable finished sheet quality, especially when processing thin stainless steel coils.
The production line can be customized according to:
- Material grade
- Coil thickness
- Coil width
- Coil weight
- Finished sheet length
- Required production speed
- Flatness requirements
- Stacking requirements
XIONGJIN Cut to Length Line Solutions
XIONGJIN MACHINERY provides customized cut to length line solutions for steel service centers and metal processors, including:
- Stop Shear Cut to Length Line
- Tracking Shear / Flying Shear Cut to Length Line
- Rotary Shear Cut to Length Line
For a customized technical solution, customers can send us their material, thickness, width, coil weight, finished sheet length and required production speed.
